  • Victron Orion HP DC/DC Converter; 20amp 24/12v

Out of stock

Victron Orion HP DC/DC Converter; 20amp 24/12v

SKU: VN-OR-NI-24-12-20
Victron Orion-Tr DC-DC Converters are available in isolated and non-isolated versions.
High efficiency Using synchronous rectification, full load efficiency exceeds 95%. IP43 protection When installed with the screw terminals oriented downwards. Screw terminals No special tools needed for installation.
Max Cable Crosssection6 mm2 / AWG10
DC ConnectionsScrew Terminals
Output Current Continuous20 A
Output Voltage V12.5 V
Off Load Current mA< 35 mA
Max Continuous Load Current25 A
Input Voltage Range V18-35 V
Galvanic IsolationNo
Efficiency Percent97%
BrandVictron
