Victron Orion TR DC/DC Converter; 8.5amp 24/48v - Isolated
SKU: VN-OR-24-48-8.5
Victron Orion-Tr DC-DC Converters are available in isolated and non-isolated versions.
Login for pricing
Remote on-off The remote on-off eliminates the need for a high current switch in the input wiring. The remote on-off can be operated with a low power switch or by for example the engine run/stop switch (see manual). Adjustable output voltage: can also be used as a battery charger For example to charge a 12 Volt starter or accessory battery in an otherwise 24V system. All models are short circuit proof and can be paralleled to increase output current An unlimited number of units can be connected in parallel. IP43 protection When installed with the screw terminals oriented downwards. Screw terminals No special tools needed for installation. Input fuse On 12V and 24V input models only.
Under Voltage Restart | 15 V |
Under Voltage Shutdown | 14 V |
Max Cable Crosssection | 13 mm2 / AWG6 |
DC Connections | Screw Terminals |
Humidity Non-Condensing | Max. 95% |
Output Current Continuous | 8.5 A |
Output Power W | 400 W |
Output Voltage V Adj | 40-60 V |
Output Voltage V | 48.2 V |
Output Noise mV | 2 mV rms |
Off Load Current mA | < 120 mA |
Max Continuous Load Current | 15 A |
Input Voltage Range V | 20-35 V |
Galvanic Isolation | Yes - 200 VDC between input, output and case |
Efficiency Percent | 89% |
Dimensions | 130 x 186 x 70mm |
Brand | Victron |
