Victron Orion TR DC/DC Converter; 5amp 148/24v - Isolated

SKU: VN-OR-48-24-5
Victron Orion-Tr DC-DC Converters are available in isolated and non-isolated versions.
Remote on-off The remote on-off eliminates the need for a high current switch in the input wiring. The remote on-off can be operated with a low power switch or by for example the engine run/stop switch (see manual). Adjustable output voltage: can also be used as a battery charger For example to charge a 12 Volt starter or accessory battery in an otherwise 24V system. All models are short circuit proof and can be paralleled to increase output current An unlimited number of units can be connected in parallel. IP43 protection When installed with the screw terminals oriented downwards. Screw terminals No special tools needed for installation. Input fuse On 12V and 24V input models only.
Under Voltage Restart30 V
Under Voltage Shutdown28 V
Max Cable Crosssection6 mm2 / AWG10
DC ConnectionsScrew Terminals
Humidity Non-CondensingMax. 95%
Output Current Continuous5:00 AM
Output Power W120 W
Output Voltage V Adj20-30 V
Output Voltage V24.2 V
Output Noise mV2 mV rms
Off Load Current mA< 50 mA
Max Continuous Load Current6.3 A
Input Voltage Range V32-70 V
Galvanic IsolationYes - 200 VDC between input, output and case
Efficiency Percent87%
Dimensions100mm x 113mm x 47mm
